The combination of smooth sliding and strong structure.
Using precision pulleys and wear-resistant tracks,
Bringing a timeless, lightweight and silent silky walking experience.
Category: Concealed Slide
Material
Zinc Plating SteelMax. loading capacity
35 KGDurability
50,000 CyclesFinish
Zinc PlatingLength
10"-24" 5 Types of Length| Parameter | Description / Specification |
|---|---|
| Material | Zinc Plating Steel |
| Max. loading capacity |
35 KG |
| Durability |
50,000 Cycles |
| Finish | Zinc Plating |
| Length specifications |
10", 12", 14", 16", 18" , 20", 22", 24"(5 Types of Length In Total) |
MK03-16
